EMCOD ML60S12DC Class 2 Magnetic Outdoor Phase cut Dimmable
Black Powder Coated Steel Enclosure
Dimensions H = 8.13, W = 3.93, D = 1.59
Remark
�The unit has additional knockout on the back
Electrical Parameters
Input Voltage: | 120V 60Hz |
Max. input current: | 0.6A at full load |
Output voltage without load: | 13.5VDC |
Output voltage fully loaded: | 11.5VDC |
Max. Total Wattage: | 60W |
Max. Output Current: | 5A |
Efficiency: | 85% |
![Electrical Diagram](https://www.emcod.com/adm_dop_files/upload_files_object/ecd1598985d291e544d5615d8afc8d60.jpg)
